The cooled cameras are sensitive in a spectral range from mid-wavelength infrared (MWIR) to long-wavelength infrared (LWIR), and reach frame rates of up to 320 Hz.
Models | IRE-320L | IRE-640L | IRE-320VL |
Data sheet | IRE-320L | IRE-640L | IRE-320VL |
Optical resolution | 320 × 256 | 640 × 512 | 1280 × 1024 |
Pixel size | 30 µm | 15 µm | 30 µm |
Spectral range | 7.7–9.5 µm | 7.7–9.5 µm | 7.7–11.5 µm |
Thermal sensitivity (NETD) | < 20 mK (15 mK typ.) | < 20 mK (15 mK typ.) | < 20 mK (15 mK typ.) |
Frame rate | variable 1–320 Hz | variable 1–120 Hz | variable 1–320 Hz |
Digital output | standard: 14-bit LVDS and camera link optional: 14-bit GigE | standard: 14-bit LVDS and camera link optional: 14-bit GigE | standard: 14-bit LVDS and camera link optional: 14-bit GigE |
Analog video output | RS-170 | RS-170 | RS-170 |
Operating temperature | –20–60 °C | –40–60 °C | –20–60 °C |
